Incoloy 800ht, Incoloy 800ht Price,

Description & Name: Incoloy 800H 800HT nickel alloy Standard: ASTM/ASME B/SB 163,ASTM /ASME B/SB407 Material: Incoloy800;

Model NO.	Incoloy 800HT
Application	Aviation, Electronics, Industrial, Medical, Chemical
Standard	JIS, GB, DIN, BS, ASTM, AISI
Purity	>99.99%
Alloy	Alloy
Type	Nickel Pipe
Powder	Not Powder
Delivery Time	7-10 Days After Order Placed.
Thickness	0.3mm-30mm
Diameter	6mm-406mm
Purity 1	>99.95% >99.99%
Transport Package	Standard Export Package.
Specification	as customers′requirement.
Trademark	Tianjin Yitejia Steel
Origin	Tianjin China
HS Code	7219900000
Production Capacity	10 Tons/Month

Description & Name: Incoloy 800H 800HT nickel alloy

Standard: ASTM/ASME B/SB 163,ASTM /ASME B/SB407

Material: Incoloy800/800H/800HT,825, Inconel 600,601,625,617,690,693, Monel 400, Monel K500, Alloy20,Alloy28. Hastelloy C276,AL6XN,N08028 etc.

UNS N08800/N08810/N08811 Chemical Composition%
Alloy Designation	Element	C	Ni	Cr	Mn	Fe	Si	Cu	Al	Ti	S
Incoloy 800	Min. %	-	30	19	-	39.5	-	-	0.15	0.15	-
Incoloy 800	Max. %	0.1	35	23	1.5	-	1	0.75	0.6	0.6	0.015
Incoloy800H	Min. %	0.05	30	19	-	39.5	-	-	0.15	0.15	-
Incoloy800H	Max. %	0.1	35	23	1.5	-	1	0.75	0.6	0.6	0.015
Incoloy800HT	Min. %	0.06	30	19	-	39.5	-	-	0.15	0.15	-
Incoloy800HT	Max. %	0.1	35	23	1.5	-	1	0.75	0.6	0.6	0.015

Mechanical Propeties	Incoloy 800	Incoloy 800H	incoloy 800HT
Density:	7.9g/cm3	7.9g/cm3	7.9g/cm3
Melting Point:	1350-1400°c	1350-1400°c	1350-1400°c
Tensile Strength Min.(Mpa):	520	450	450
Yield Strength Min. (MPa): 0.2% offset	205	170	170
Elongation A 5%(min.):	30	30	30
Rockwell Hardness Max.:	B95	B95	B95

Product	Thickness	Diameter	Wall Thickness	Width	Length
Plate	0.3mm-30mm			1m/1.22m/1.5m	1m-11.8m
Bar		2mm-300mm			1m-5m
Pipe		6mm-406mm	0.3mm-30mm
Forging	30mm-300mm	300mm-800mm			0.2m-1m
For the plate, bar and pipe, we can cut for you according to your required length from our stock.
